3/8 PVC Encapsulated Control Line Tubing

Product Description

3 / 8 " OD X 0.049 " Control line tubing with PVC encapsulation

The encapsulated tubing are designed to protect the (duplex) stainless steel tubing coils free from various harsh corrosion environments. Tube will be Encapsulated with high performance thermoplastic or elastomer materials, and could withstand the temperature of 150C or 200C operating temperature environments.The tube size and encapsulation material can be made as per requirement, Flatpack is also available.

Application:

• Downhole hydraulic control lines.
• Downhole chemical control lines.
• Subsea control lines for hydraulic power and chemical injection.
• Smoothbore control lines used in fibre optic applications.
• Chemical Injection Lines
• Capillary Tubing
• Electrical Lines
• Tubing Encapsulated Conductor
• Intelligent Well Completions
• Multi-Line Flat Packs

Aailable materials: Austenitic steel 304L, 316L, Duplex 2205 ,Super Duplex 2507 ,Incoloy 825, Inconel 625

OD size:1/8"; 3/16";1/4";5/16";3/8";1/2"

Wall thickness:0.02",0.028",0.035",0.049",0.065".0.083"

Encapsulation materials:Santoprene,F40;F46;FEP (Fluorinated Ethylene Propylene);PVC (Polyvinyl chloride);Nylon Encapsulated etc..

Available Encapsulation shapes: Round Type, Square type, Flatpack

We welcome to your contact!
