F46 Encapsulated Control Line Tubing 1/8" OD
Contact Person : Dan Zhang
Phone Number : 86-13679121121
WhatsApp : +8613679121121
Detail Information |
|||
Technique: | Cold Drawn | Product Name: | Encapsulated Control Line |
---|---|---|---|
Machine Type: | Steel 304L (UNS S30403) Austenitic Steel 316L (UNS S31603) Duplex 2205 (UNS S32205 & S31803) Super Duplex 2507 (UNS S32750) Incoloy 825 (UNS N08825) Inconel 625 (UNS N06625) | Processing Type: | Welded&seamless |
OD: | 1/8"-1/2" | Thickness: | 0.025"-0.083" |
High Light: | 1/2" Ss Chemical Injection Tubing,1/2" Seamless Chemical Injection Tubing,0.083" UNS S30403 Injection Tubing |
Product Description
The encapsulated tubing are designed to protect the (duplex) stainless steel tubing coils free from various harsh corrosion environments. Tube will be Encapsulated with high performance thermoplastic or elastomer materials, and could withstand the temperature of 150C or 200C operating temperature environments.The tube size and encapsulation material can be made as per requirement, Flatpack is also available.
Chemical Composition,% | ||||||||
Standard | ASTM A269 | ASTM A789 | ASTM B704 | |||||
Material | SS 304 | SS 304L | SS 316 | SS 316L | Duplex 2205 | Super Duplex 2507 | Incoloy 625 | Incoloy 825 |
UNS | S30400 | S30403 | S31600 | S31603 | S32205 | S32750 | N06625 | N08825 |
C | 0.080 | 0.035 | 0.080 | 0.035 | 0.030 | 0.030 | 0.10 | 0.05 |
Mn | 2.00 | 2.00 | 2.00 | 2.00 | 2.00 | 1.20 | 0.50 | 1.00 |
P | 0.045 | 0.045 | 0.045 | 0.045 | 0.030 | 0.035 | 0.015 | ... |
S | 0.030 | 0.030 | 0.030 | 0.030 | 0.020 | 0.020 | 0.015 | 0.030 |
Si | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 0.80 | 0.50 | 0.50 |
Ni | 8.0-11.0 | 8.0-12.0 | 10.0-14.0 | 10.0-15.0 | 4.5-6.5 | 6.0-8.0 | min 58.0 | 38.0-46.0 |
Cr | 18.0-20.0 | 18.0-20.0 | 16.0-18.0 | 16.0-18.0 | 22.0-23.0 | 24.0-26.0 | 20.0-23.0 | 19.5-23.5 |
Mo | ... | ... | 2.00-3.00 | 2.00-3.00 | 3.0-3.5 | 3.0-3.5 | 8.0-10.0 | 2.5-3.5 |
N | ... | ... | ... | ... | 0.14-0.20 | 0.24-0.32 | ... | ... |
Cu | ... | ... | ... | ... | ... | 0.50 | ... | 1.5-3.0 |
Fe | 5.0 | min 22.0 | ||||||
Al | 0.4 | 0.2 | ||||||
Ti | 0.40 | 0.6-1.2 | ||||||
Cb+Ta | 3.15-4.15 | ... |
We welcome to your contact!
OD size:1/8"; 3/16";1/4";5/16";3/8";1/2"
Wall thickness:0.02",0.028",0.035",0.049",0.065".0.083"
Aailable materials: Austenitic steel 304L, 316L, Duplex 2205 ,Super Duplex 2507 ,Incoloy 825, Inconel 625
Encapsulation materials:Santoprene,F40;F46;FEP (Fluorinated Ethylene Propylene);PVC (Polyvinyl chloride);Nylon Encapsulated etc..
Available Encapsulation shapes: Round Type, Square type, Flatpack
