Name: CT110 Continuous Coiled Tubing
Brand: Tiptop
SKU: CT80
Rating: 5 (170 reviews)

Detail Information
Material:	CT110	Technique:	Cold Drawn
Standard:	API 5ST	Processing Type:	Seamless & Welded
OD:	1 3/4"	Thickness:	0.095"~0.25"
High Light:	1 3/4 " CT110 Continuous Coiled Tubing , 0.25" API 5ST CT110 , 0.25" API 5ST Coiled Tubing

Product Description

1 3 / 4 " CT110 API 5ST Continuous Coiled Tubing for Downhole Operation

CT110 tube belongs to conventional coiled tubing, as one of the main products of our company, CT110 coiled tubing has the advantages of high strength, high pressure resistance, high fatigue life and strong environmental adaptability. Our products are fully compliant with API spec 5ST and all other industry standard. Complete in size and specification, our tubing can meet various operating conditions.

Chemistry Composition

Grade	max C	max Mn	max P	max S	max Si
CT110	0.16	1.65	0.025	0.005	0.50

The detailed dimension and parameter information are shown in the following table for your reference.

OD	Thickness		U-Weight	yield strength	Tension strength	Loading of pipe body		Min. test pressure
OD	specified	Min.	U-Weight	yield strength	Tension strength	Min. yield force	Min. tension force	Min. test pressure
Inch	Inch	Inch	lbs/ft	psi	psi	lbs	lbs	psi
3/4	0.08~0.118	0.075~0.11	0.57~0.8	110000	115000	18500~25800	19400~26900	15000~15000
1	0.075~0.134	0.07~0.126	0.74~1.24	110000	115000	24000~40100	25100~41900	13100~15000
1 1/4	0.075~0.175	0.07~0.167	0.94~2.01	110000	115000	30500~65000	31800~68000	10500~15000
1 1/2	0.087~0.204	0.082~0.196	1.31~2.83	110000	115000	42500~91400	44400~95500	10200~15000
1 3/4	0.095~0.25	0.09~0.242	1.68~4.01	110000	115000	54300~129600	56800~135500	9600~15000
2	0.109~0.281	0.104~0.266	2.2~5.16	110000	115000	71200~166900	74500~174500	9700~15000
2 3/8	0.109~0.3	0.104~0.285	2.64~6.65	110000	115000	85400~215100	89200~224900	8200~15000
2 5/8	0.118~0.3	0.11~0.285	3.15~7.46	110000	115000	102200~241000	106900~252000	7800~15000
2 7/8	0.134~0.3	0.126~0.285	3.93~8.26	110000	115000	126900~267000	132700~279100	8200~15000
3 1/4	0.145~0.3	0.137~0.285	4.81~9.46	110000	115000	155600~305800	162700~319700	7900~15000
3 1/2	0.156~0.3	0.148~0.285	5.58~10.26	110000	115000	180300~331800	188500~346800	7900~15000

The main information are as follows:

Coiled tubing type: Conventional

Steel grade: CT110

Advantages: High strength, Anti-fatigue

Standard: API 5ST

Outside Diameter: 3/4 " ~ 3 1/2 " (19.1 mm to 88.9 mm)

Wall Thickness: 0.075 " ~ 0.3 " (1.9mm~7.6mm)

Mechanical Properties

Min. Tensile Strength: 115,000psi ( 793Mpa)

Min. Yield Strength: 110,000psi ( 758Mpa)

Max. Hardness: 30HRC
