F46 Encapsulated Control Line Tubing 1/8" OD
Contact Person : Dan Zhang
Phone Number : 86-13679121121
WhatsApp : +8613679121121
Minimum Order Quantity : | 1 reel | Price : | USD/EURO/RMB |
---|---|---|---|
Packaging Details : | wooden reel + wooden case | Delivery Time : | one week |
Payment Terms : | L/C, T/T |
Place of Origin: | China | Brand Name: | Tiptop |
---|---|---|---|
Certification: | ISO9001 | Model Number: | 3 / 8 " x 0.035 " |
Detail Information |
|||
Technique: | Cold Drawn | Product Name: | Encapsulated Control Line |
---|---|---|---|
Machine Type: | Steel 304L (UNS S30403) Austenitic Steel 316L (UNS S31603) Duplex 2205 (UNS S32205 & S31803) Super Duplex 2507 (UNS S32750) Incoloy 825 (UNS N08825) Inconel 625 (UNS N06625) | Processing Type: | Welded&seamless |
OD: | 1/8"-1/2" | Thickness: | 0.025"-0.083" |
High Light: | 0.083" Super Duplex Coiled Line Pipe,1/2" Coiled Steel Tubing,0.025" Stainless Coiled Tubing |
Product Description
Three pieces of 3/8" x 0.065" Encapsulated Line tubing flatpacked in a 34mm X 13mm jacket, The encapsulation materials can be Santoprene or others nominated by customer, three pieces of control line tubing could have ink color code. Tube material can be weather stailess steel or alloy steel like Incoloy 825 or Incoloy 625 or super duplex stailess steel . Inside of tube,can be pre-flushed, tested and supplied with any fluid,The Flatpack finally will be level wound on wooden or metal drum and install protector to prevent from mechanical damage.
Encapsulation materials:Santoprene,F40;F46;FEP (Fluorinated Ethylene Propylene);PVC (Polyvinyl chloride);Nylon Encapsulated etc..
Application:SCSSV,Downhole Chemical Injection, Well Completions,Gauge Application
OD | Wall (inch) |
Materials | Standard | Working Pressure (MPa) |
Length |
1/8" | 0.02,0.028,0.035 | Austenitic steel 304L (UNS S30403) Austenitic steel 316L (UNS S31603) Duplex 2205 (UNS S32205 & S31803) Super Duplex 2507 (UNS S32750) Incoloy 825 (UNS N08825) Inconel 625 (UNS N06625) |
ASTM-A 269 ASTM-A 632 ASTM-A 789 ASTM-B 704 |
60-120 Mpa | Customized |
3/16" | 0.02,0.028,0.035,0.049 | ||||
1/4" |
0.02,0.028,0.035,0.049 0.065.0.083 |
||||
5/16" | |||||
3/8" | |||||
1/2" | |||||
OD: Up to 1 Inch The specification and length per coil can be customized according to customer’s requirements. |
Chemical Composition,% | ||||||||
Standard | ASTM A269 | ASTM A789 | ASTM B704 | |||||
Material | SS 304 | SS 304L | SS 316 | SS 316L | Duplex 2205 | Super Duplex 2507 | Incoloy 625 | Incoloy 825 |
UNS | S30400 | S30403 | S31600 | S31603 | S32205 | S32750 | N06625 | N08825 |
C | 0.080 | 0.035 | 0.080 | 0.035 | 0.030 | 0.030 | 0.10 | 0.05 |
Mn | 2.00 | 2.00 | 2.00 | 2.00 | 2.00 | 1.20 | 0.50 | 1.00 |
P | 0.045 | 0.045 | 0.045 | 0.045 | 0.030 | 0.035 | 0.015 | ... |
S | 0.030 | 0.030 | 0.030 | 0.030 | 0.020 | 0.020 | 0.015 | 0.030 |
Si | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 0.80 | 0.50 | 0.50 |
Ni | 8.0-11.0 | 8.0-12.0 | 10.0-14.0 | 10.0-15.0 | 4.5-6.5 | 6.0-8.0 | min 58.0 | 38.0-46.0 |
Cr | 18.0-20.0 | 18.0-20.0 | 16.0-18.0 | 16.0-18.0 | 22.0-23.0 | 24.0-26.0 | 20.0-23.0 | 19.5-23.5 |
Mo | ... | ... | 2.00-3.00 | 2.00-3.00 | 3.0-3.5 | 3.0-3.5 | 8.0-10.0 | 2.5-3.5 |
N | ... | ... | ... | ... | 0.14-0.20 | 0.24-0.32 | ... | ... |
Cu | ... | ... | ... | ... | ... | 0.50 | ... | 1.5-3.0 |
Fe | 5.0 | min 22.0 | ||||||
Al | 0.4 | 0.2 | ||||||
Ti | 0.40 | 0.6-1.2 | ||||||
Cb+Ta | 3.15-4.15 | ... |
