Control Line Incoloy 625 Seamless Stainless Steel Coils
Contact Person : Dan Zhang
Phone Number : 86-13679121121
WhatsApp : +8613679121121
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Seaworthy wooden cases or wooden reels | Delivery Time : | 10 days |
Payment Terms : | T/T | Supply Ability : | 1000 tons per month |
Place of Origin: | CHINA | Brand Name: | TIPTOP |
---|---|---|---|
Certification: | ISO | Model Number: | 316 |
Detail Information |
|||
Material: | 316,304 | Standard: | ASTM A269 |
---|---|---|---|
Length: | According To The Sizes | Processing: | Bending, Welding, Cutting |
OD: | 1/16"~1" | Thickness: | 0.02"~0.083" |
High Light: | 304L Stainless Steel Pipe Coil,UNS S30403 SS Pipe Coil,ASTM A269 SS Pipe Coil |
Product Description
Tiptop has more than 15 years of experience and expertise on every seamless tubing product that we supply and we have a wide range of sizes in stock available for immediate delivery.
In applications where corrosion resistance and higher pressure seamless stainless tubing are required, we are your best choice.Besides 2.5% Minimum Moly, 316/316L stock coils, we can also provide material in 304/304L, 317/317L, 625, 825, and Duplex 2205. Other high performance and corrosion resistant alloys are available upon request.
Stainless Steel Coil Tube Specifications – Restricted Tolerance Controls
OD Tolerance: +0.005/-0 in.
Hardness: Maximum 80 HRB (Rockwell)
Wall Thickness: ±10%
Chemistry: Min. 2.5% Molybdenum
Stainless Steel Coil Tube Chemical Composition
The below table shows the chemical composition of the used for Stainless Steel Coil Tubes:
GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
