60-120 Mpa Seamless Hydraulic Control Line Tube Customized Length
Contact Person : Dan Zhang
Phone Number : 86-13679121121
WhatsApp : +8613679121121
|Minimum Order Quantity :||1 reel||Price :||USD/EURO/RMB|
|Packaging Details :||WOODEN REEL +WOODEN CASE||Delivery Time :||ONE WEEL|
|Payment Terms :||L/C, T/T,||Supply Ability :||1000 TONS PER MONTH|
|Place of Origin:||China||Brand Name:||Tiptop|
|Certification:||ISO 9001||Model Number:||825|
|Material:||UNS N08825||Technique:||Cold Drawn|
|Standard:||ASTM-A 269 ASTM-A 632 ASTM-A 789 ASTM-B 704||Processing Type:||Seamless & Welded|
UNS N08825 Control Line Tube,
ASTM-B 704 Hydraulic Control Line Tube,
UNS N08825 Seamless Hydraulic Control Line
Incoloy 825 is a nickel-based alloy with high Ni and high corrosion resistance. It has high corrosion resistance to both oxidizing and non-oxidizing acids.
Because Incoloy 825 alloy is rich in Cr, Mo, Cu, it has good general corrosion resistance to oxidizing acid and non-oxidizing acid. Especially it has extremely high corrosion resistance to sulfuric acid. Due to the high content of Cr, Mo and Ni, it has excellent pitting corrosion resistance, crevice corrosion resistance, and stress corrosion cracking resistance in a chloride environment. Incoloy 825 alloy controls the carbon content at an extremely low level, is not easy to be sensitized during welding, and has low intergranular corrosion sensitivity.
Size Chart of UNS N08825 Seamless Hydraulic Control Line Tube 0.02"-0.083" WT
|1/8"||0.02", 0.028", 0.035"||Incoloy 825 (UNS N08825)||ASTM-A 269
|3/16"||0.02", 0.028", 0.035", 0.049"|
|1/4"||0.02", 0.028", 0.035", 0.049", 0.065", 0.083"|
|* OD: Up to 1"|
Applications of UNS N08825 Seamless Hydraulic Control Line Tube 0.02"-0.083" WT
1. Heating pipes, containers, baskets and chains used in sulfuric acid pickling plants;
2. Sea water cooling heat exchanger, marine product pipeline system;
3. Acid gas environment pipelines, heat exchangers, evaporators, scrubbers, dip tubes, etc. in phosphoric acid production;
4. Air heat exchanger in petroleum refining.
5. Food engineering chemical process, flame retardant alloy for high pressure oxygen application
Q1: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q2: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.
Q3. Can you provide customize service?
A: Yes.Pipes can be customized as per the customers' request.
Q4. How to ensure the quality?
A: Mill Test Certificate is supplied with shipment.
If needed, a Third Party Inspection is acceptable.
